Fiber-to-the-Home Cable Production: Step-by-Step Manufacturing Process
Quick fact: more than seventy percent of new U.S. broadband builds now use fiber networks that demand precise manufacturing to meet performance goals.
Shanghai Weiye OFC Equipment handles full-cycle SZ stranding line manufacturing, from selecting brand fibers like Fujikura® or Corning® SMF-28e to complete test reports that guarantee full quality assurance.
Our drop cable designs are built for aerial, underground, and direct burial installation, with LSZH, PVC, and PE jacket options and core counts from 1–4 cores. We offer single-mode OS1/OS2 and OM2–OM4 grades plus G.652D and G.657 variants, Pantone sheath colors, and logo printing.
Automation and high-precision equipment stabilize line speed and repeatability high. Typical lead times run four to five days for orders under 100 km and seven to ten days under 500 km, with an MOQ of 1 km and warranty covering free replacement for confirmed quality issues.
Continue to learn how materials, testing, and support work together to reduce lifecycle cost and pair the right product with your network.
- Shanghai Weiye OFC Equipment offers complete production and laboratory testing for United States projects.
- A range of jacket options and fiber grades cover indoor/outdoor environments.
- Automated lines and machines deliver stable quality and stable optical performance.
- Quick lead times, low MOQ, and recognized brand fibers help plan procurement reliably.
- Complete reports and after-sales warranty back product reliability and documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When schedules and performance count, Shanghai Weiye OFC Equipment provides tailored drop solutions with complete test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment pairs purpose-built equipment with tight material control. We offer custom builds and services for residential and MDU rollouts. Every order comes with 100% quality assurance and complete test reports.
Our lab performs high-temperature, salt-fog, and vibration tests to verify durability. Jacket options cover LSZH, PVC, and PE. Designs include flat bow-type and self-supporting styles and support brand fibers such as Fujikura® and Corning® SMF-28e.
- Documented line control and production checks for auditable shipments.
- Engineering support for specification reviews, trials, and volume ramp.
- Modern fixturing and calibration reduce variability so every cable meets operator standards.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are matched to network specs, combining brand fiber choices with strict test routines.
Selecting Optical Fiber and Brands
We align Fiber coloring machine to bend radius, attenuation, and install environment. Options include OS1/OS2 and OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura and Corning® SMF-28e are available to meet procurement standards.
Strength Member Options
Strength members use dielectric FRP or galvanized steel wire. FRP is ideal where non-conductive runs are required. Steel wire provides tensile strength for long-span aerial runs and grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for indoor flame safety, PVC for flexibility and ease of handling, and PE for outdoor UV and moisture resistance. Closed-loop control of extruder temperature and capstan speed keeps line speed stable and dimensional tolerances.
| Member | Dielectric FRP | Steel wire |
|---|---|---|
| Primary use | Non-conductive runs | High-tension aerial runs |
| Key benefit | Lightweight, inert | High strength |
| Installer note | Simple terminations | Requires grounding |
Testing & Verification
Inline geometry/concentricity checks run during manufacturing. Final optical tests verify loss and reflectance. Each order includes a 100% test report and lab results from high heat, salt fog, and vibration tests to qualify field handling and drop terminations.
Typical lead times are under 100 km in 4–5 days and under 500 km in 7–10 days. Lot records and first-article approvals support traceability and compliance for U.S. projects.
Our FTTH Drop Cable Types and Structures
Shanghai Weiye OFC Equipment provides a focused portfolio of FTTH drop designs that fit indoor risers and long aerial runs. Each option combines tested materials with field-termination geometry and stable optical performance.
The flat bow-type drop minimizes footprint for risers/ducts. It reduces bend loss for simple routing in hallways and MDUs.
Self-Supporting Aerial Designs
Self-supporting FTTH drop designs use a messenger element to handle tension. Choose FRP (dielectric) for non-conductive runs or steel messenger when bonding and higher tensile strength are required.
Strength member and core layouts
We provide both dielectric and metallic strength member configurations to match safety and EMI rules. Central loose-tube and flat unitube types balance crush resistance and Fiber draw tower for fast terminations.
Indoor vs Outdoor Jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor durability. Each series is qualified for mechanical/optical performance before shipment.
| Type | Application | Strength member | Sheath |
|---|---|---|---|
| Bow-type flat | Indoor risers and MDUs | Dielectric FRP | LSZH |
| Self-supporting | Aerial spans | Steel wire or FRP | Polyethylene |
| Central loose-tube | Higher fiber counts | Dielectric FRP | LSZH/PE |
| Unitube flat | Low count, quick strip | FRP or steel | LSZH/PE |
Production Assets for Speed and Quality
Automation with sensor feedback at Shanghai Weiye OFC Equipment reduce manual handling and increase throughput for patch cord prep.
Our production line uses automated machines that cut/strip drop cords to raise throughput and cut labor variability.
The CLX-BPO2 automated stripper uses PLC + photoelectric control. One cycle is ~1.5 s, giving real-world speeds near 20 terminal operations per minute.
Automated cutting and stripping for drop cable patch cords
The equipment strips LSZH and PVC jackets and trims FRP or steel strength members to precise reserved lengths. Cylinder-driven actuators provide quick, repeatable motion and minimize downtime.
Closed-Loop Control for Repeatability
PLC logic and photoelectric sensors deliver precise positioning and feedback control. Inline checks update SPC charts so operators can correct trends before defects grow.
| Feature | Capability | Benefit |
|---|---|---|
| Machine | 1.5s cycle, auto-strip | ~20 terminals/minute throughput |
| Actuation | Pneumatic cylinders | Fast/reliable motion |
| Materials | LSZH/PVC; FRP/steel | Clean, accurate preps |
| Control | PLC + photoelectric + inline checks | Consistent quality, lower rework |
- Auto scrap ejection and ergonomic feeders keep the line clean.
- Process control plans capture calibration intervals and critical parameters.
- Combined machines, fixtures, and trained staff help meet FTTH volume goals without compromising accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to raise output and standardize prep quality. The unit cycles in ~1.5 seconds, producing around 20 preps per minute in production.
PLC/photoelectric control deliver exact detection and repeatable motion. That control keeps strip and stub lengths within tight tolerances.
Cycle time and throughput
Typical operation speed is ~1.5 seconds per cycle. This enables steady throughput under continuous line conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 strips LSZH and PVC jackets with an adjustable jacket strip length from 17.5–35.0 mm. Reserved strength member stubs are adjustable from 7.0–11.0 mm to match common termination hardware.
Handling FRP and steel wire strength members
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Customized cutters are available for nonstandard sizes to maintain precision.
- Automatic waste ejection and sensor-triggered start cut idle time.
- Small footprint (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg mass ease integration into workcells.
- Cylinder-driven motion and closed-loop control boost reliability and lower maintenance interruptions.
| Spec | Value | Why it matters |
|---|---|---|
| Cycle time | ~1.5 s (~20/min) | Supports high-volume runs |
| Jacket strip (A) | 17.5 to 35.0 mm | Fits common connector processes |
| Stub (B) | 7.0 to 11.0 mm | Supports termination strength |
| Power/Size | 110–220V, 50W; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams receive drop parts ready for quick installation. The CLX-BPO2 helps our production lines meet volume goals without compromising quality.
Tailored Specifications for Your Network
Shanghai Weiye OFC Equipment configures each build to meet your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1 to 4 cores with single-mode or multimode fiber. Options include OS1/OS2 plus OM2–OM4 along with G.652D/G.657 variants to align with optics and connector plans.
We Pantone-match sheath colors for quick field identification and consistent asset tagging.
Jacket materials, print legends, and branding
Select LSZH/PVC/PE jackets based on route and safety rules. Custom legends/logos support inventory and warranty tracking.
Lengths, Packaging & Special Builds
Standard reel lengths are 1/2/4 km with tailored reels and packaging to suit storage and handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to fit span and isolation requirements.
| Option | Common choice | Advantage |
|---|---|---|
| Length | 1, 2, or 4 km | Simpler staging and reels |
| Jacket | LSZH, PE, PVC | Indoor/outdoor compatibility |
| Structure | Bow-type / Self-supporting | Flexible routing/span |
As a supplier, Shanghai Weiye aligns runs to your schedule and delivers documentation that lists final specifications for straightforward QA on site.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
High-temperature, salt spray, and vibration laboratory testing
Our lab conducts high-temperature exposure, salt fog corrosion, and mechanical vibration to qualify materials and assemblies. These tests simulate field stresses for indoor/outdoor applications.
100% test reports for every cable
Every fiber optic cable ships with a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.
Audit Trail and Compliance
Lot/batch records tie test data to reels and serials so audits and claims are easy to verify. Documentation uses standard customer templates to speed approvals and inbound inspection.
- Line checks and final inspection reduce field failures and cut warranty events.
- Quality packages include specifications confirmation and formatted data for quick review.
- Continuous test trends drive preventive maintenance and raise long-term reliability.
| Test | Why | Result |
|---|---|---|
| Heat exposure | Material stability | Pass at target temperature |
| Salt spray | Corrosion robustness | Qualified for outdoor use |
| Vibration | Resistance to vibration | Improved field reliability |
Cost Drivers and Pricing
Budget planning for a drop begins with fiber/jacket selection and is refined by volume and customization.
Typical prices range broadly—from about $30–$1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket material, length, and structural design.
Material choices, fiber grade, jacket type, and structure
The primary cost drivers are fiber optic grade, sheath material, and the chosen structure for deployment.
Self-supporting designs and steel members raise material and labor input. Custom colors, logos, and print legends add setup time and impact pricing on small runs.
How Volume & Options Affect Cost
Longer put-ups and larger volumes reduce unit cost. Short runs often carry setup fees and higher unit prices.
- Line changeovers and custom tooling extend lead time and add to cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets across phases.
| Driver | Price impact | Guidance |
|---|---|---|
| Fiber grade | High impact | Right-size spec to budget |
| Jacket type | Medium impact | Compare LSZH vs. PE for total cost |
| Order length / volume | Large | Consolidate where possible |
U.S. Lead Times, MOQ & Delivery
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align staffing and sites. Predictable schedules cut downtime and control costs when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for orders under 500 km. We schedule line capacity to match your rollout milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams can plan arrivals. For compressed schedules, we hold contingency capacity to accelerate critical-path orders.
Minimum order quantity and why it matters
The MOQ is one kilometer. This reflects line setup such as wire/die adjustments that use startup material and generate scrap.
We review your put-ups and staging to choose reel sizes that cut waste and handling. Staggered batches can balance inventory holding with more frequent small-site deliveries.
Installation readiness and application scenarios
On-site conditions dictate whether a self-supporting span, duct pull, or direct burial is the right choice for a project.
Aerial vs Duct vs Direct-Buried
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with appropriate members to manage sag/tension for long-term stability.
Duct installations perform best with low-friction sheaths and crush-resistant constructs so pulling avoids fiber damage. PE jackets are typical for underground and buried paths where moisture resistance matters.
Direct-buried designs need correct burial depth per local codes and moisture barriers to protect the fiber core long-term.
Indoor Riser/Plenum & ONT
Indoor riser and plenum routes favor LSZH jackets to meet smoke/flame codes. Flat drop cable forms strip clean and present controlled strength stubs for quick ONT termination.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning risk, and hardware compatibility. Standardized prep from the production line shortens install time and minimizes scrap.
| Scenario | Key feature | Field note |
|---|---|---|
| Overhead | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Underground duct | Low-friction jacket, crush resistance | Use pull tape + lubricant |
| Direct-buried | PE with moisture barrier | Follow depth/warning tape codes |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at penetrations |
Our approach delivers a consistent installation across indoor outdoor transitions. That leads to fewer callbacks, faster activations, and reliable field performance for your system.
Comprehensive Support & After-Sales
Our team coordinates tests, line schedules, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements capture through approved drawings and pilot builds. We provide doc templates and clear installation notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full reports and traceability to support QA acceptance.
- Round-the-clock availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for urgent changes or acceleration requests.
- Configuration control so shipped items match agreed specs consistently.
| Support area | What we do | Outcome |
|---|---|---|
| Engineering | Spec review & pre-production builds | Fewer field issues |
| QA/Testing | Lab + 100% reports | Traceable quality |
| After-sales | Rapid replacement & root-cause | Minimized downtime |
Final Thoughts
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We provide custom FTTH drops that pair material choices with validated manufacturing and lab testing. Every reel includes a 100% test report and documented lab trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2 prep assets, reduces variability and speeds turnaround. Our equipment and machines standardize strip and stub lengths so installers see consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to maximize service life. Dedicated support covers scheduling/logistics/after-sales so your deployment remains on plan.
Contact Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive support.
